9000m Highly-stable Laser Ranging Module

Name: 9000m Highly-stable Laser Ranging Module
Brand: Hainan Eyoung Technology Co., Ltd.

Our 9000m Highly-stable Laser Ranging Module enables highly-stable laser emission and highly accurate range acquisition from low to high reflection standard Nato targets up to 9 kilometers. Adopted with 1535nm laser wavelength, which has good penetration through air, minimal atmospheric absorption, it provides more accurate ranging over longer distance compared to 905nm wavelength. Robust and integrated design, the unit remain resistant to wear and withstand even the most unforgiving weather conditions. Thus it can be effectively used in marine navigation, long-range reconnaissance, security systems and other professional applications requiring highly accurate, long distance measurements.

Send Mail

Share It :

Drawing of 9000m Highly-stable Laser Ranging Module

Long Range Distance Sensor

Drawing of 9000m Highly-stable Laser Ranging Module

Specifications of 9000m Highly-stable Laser Ranging Module

Items		Index
Laser wavelength		1535nm
Maximum range (m)	Large target	12500
	Vehicle（2.3m×4.6m）	9500
	Human（0.5m×1.7m）	4500
Minimum range (m)		80
Ranging accuracy (m)		±1
Size (L×W×H) (mm)		≤86.5×66.5×45.5
Weight (g)		≤150
Ranging frequency (Hz)		Single time, 1, 5
Accuracy rate		≥98%
False alarm rate		≤1%
Multiple target detection (pc)		2
Communication Interface		RS422
Supply voltage (V)		12±2
Standby power consumption (W)		≤1W, power off to achieve zero standby power consumption
Operating temperature		-40～+60℃

Features of 9000m Highly-stable Laser Ranging Module

Simultaneously 2 targets detection
Customizable serial port and lens colour
Fastest continuous operation rate at 5Hz
Incredible ranging capability of vehicle up to 9000m
Power-off to realize no power consumption in stand-by mode
Wide operating temperature range with no degradation of range performance

Applications of 9000m Highly-stable Laser Ranging Module

Electro-optical Pods:

With its SWaP and rugged design, this laser rangefinder module is perfect for drones and UAVs. It is capable of high-precision altitude measurements, obstacle detection, and terrain mapping etc.

Aerospace and Defense:

With its high accuracy and robust design, this module is ideal for use in aerospace and defense applications, such as missile guidance.

Scientific Research:

This module is ideal for use in scientific research applications where accurate measurements are required, such as in geology, physics, and environmental science.
